ESPECIFICACIONES

Camera

Image Sensor: 1/3” 1.3Megapixel progressive CMOS
Effective Pixels: 1280(H) x960(V)
RAM/ROM: 256MB/16MB
Scanning System: Progressive
Minimum Illumination: 0.5Lux/F2.2(Color), 0Lux/F2.2(IR on)
S/N Ratio: More than 50dB
IR Distance: Distance up to 10m(33ft)
IR On/Off Control: Auto/ Manual
IR LEDs: 1

Lens

Lens Type: Fixed
Mount Type: Board-in
Focal Length: 2.3mm
Max. Aperture: F2.2
Angle of View: H:125°;V:89°
Focus Control: Fixed
Close Focus Distance: N/A

PTZ

Pan/Tilt Range: Pan:0° ~360° ;Tilt:-10° ~90° ;Rotation:0° ~360°

Video

Compression: H.264/H.264B/H.264H/MJPEG
Streaming Capability: 2 Streams
Resolution: 1.3M(1280×960)/720P(1280×720)/VGA(640×480)/QVGA(320×240)
Frame Rate: 1.3M(1~25/30fps) ; VGA/QVGA(1~25/30fps)
Bit Rate Control: CBR/VBR
Bit Rate: H264:32K ~ 10240Kbps
Day/Night: Auto(ICR) / Color / B/W
BLC Mode: BLC / HLC / DWDRWhite Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detection: Off / On (4 Zone, Rectangle)
Electronic Image: Support
Smart IR: Support
Digital Zoom: 16x
Flip: 0°/90°/180°/270°
Mirror: Off / On
Privacy Masking: Off / On (4 Area, Rectangle)

Audio

Compression: G.711A;G.711Mu;AAC

Network

Wi-Fi: Wi-Fi(IEEE802.11b/g/n),50m(open field)
Protocol: HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;
DHCP;DNS;DDNS;IPv4/v6;QoS;UPnP;NTP;Bonjour;Multicast;ICMP;IGMP;
Interoperability: PSIA, CGI
Streaming Method: Unicast / Multicast
Max. User Access: 10 Users/20 Users
Edge Storage: NAS(Network Attached Storage),Local PC for instantrecording,Micro SD Card(up to 128GB)
Web Viewer: IE, Chrome, Firefox, Safari
Management Software: Smart PSS, DSS, Lechange
Smart Phone: iOS, Android

Certifications

Certifications: CE (EN 60950:2000); UL:UL60950-1; FCC: FCC Part 15 Subpart B

Interface

Video Interface: N/A
Audio Interface: Built-in Mic & Speaker
RS485: N/A
Alarm: N/A

Electrical

Power Supply: DC5V 1A
Power Consumption: <4.7W Environmental Operating Conditions: -10°C ~ +45°C (14°F ~ +113°F) / Less than 95% RH Strorage Conditions: -10°C ~ +45°C (14°F ~ +113°F) / Less than 95% RH Ingress Protection: N/A Vandal Resistance: N/A Construction Casing: Plastic Dimensions: 64.4mm*55.7mm*107mm(2.54'’ x2.19’’x4.21’’) Net Weight: 0.135Kg(0.30lb) Gross Weight: 0.36Kg(0.79lb) Construction Casing: Plastic Dimensions: 64.4mm*55.7mm*107mm(2.54'’ x2.19’’x4.21’’) Net Weight: 0.135Kg(0.30lb) Gross Weight: 0.36Kg(0.79lb)
