DVR/NVR 32CH DAHUA H.265+ 2HDD SMART CODEC IVS (XVR5232AN-X)

DVR/NVR 32CH DAHUA H.265+ 2HDD SMART CODEC IVS (XVR5232AN-X)

$0,00

> H.265+/H.265 dual-stream video compression
> Supports HDCVI/AHD/TVI/CVBS/IP video inputs
> Max 32 channels IP camera inputs, each channel up to 6MP; Max 128Mbps Incoming Bandwidth
> Smart Search and Intelligent Video System

Disponibilidad: Agotado Categoría: Brand: Dahua

Descripción

Part number XVR5232AN-X

Información adicional

Marca

DAHUA

ESPECIFICACIONES

System

Main Processor: Embedded Processor
Operating System: Embedded LINUX

Video and Audio

Analog Camera Input: 32 Channel, BNC
HDCVI Camera: 5MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
AHD Camera: 5MP, 4MP, 1080P@25/30, 720P@25/30fps
TVI Camera: 5MP, 4MP, 1080P@25/30, 720P@25/30fps
CVBS Camera: PAL/NTSC
IP Camera Input: 32 Channel, each channel up to 6MP
Audio In/Out: 1/1, RCA
Two-way Talk: Reuse audio in/out, RCA

Recording

Compression: H.265+/H.265/H.264+/H.264
Resolution: 5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF
Record Rate: Main stream:5M-N(1~10fps), 4M-N/1080P(1~15fps),
1080N/720P/960H/D1/CIF (1~25/30fps) ; Sub stream: D1/CIF(1~15fps)
Bit Rate: 32Kbps ~ 6144Kbps Per Channel
Record Mode: Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval: 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post
record: 10 ~ 300 sec
Audio Compression: AAC(only for the 1st channel), G.711A, G.711U, PCM
Audio Sample Rate: 8KHz, 16 bit Per Channel
Audio Bit Rate: 64Kbps Per Channel

Display

Interface: 1 HDMI ,1 VGA
Resolution: HDMI:3840×2160, 2560×1440, 1920×1080, 1280×1024,
1280×720 ; VGA: 1920×1080, 1280×1024, 1280×720
Multi-screen Display: 1/4/8/9/16/25/36
OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Network

Interface: 1 RJ-45 Port (1000M)
Network Function: HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports IP camera, DVR, NVS, etc.)
Max. User Access: 128 users
Smart Phone: iPhone, iPad, Android
Interoperability: ONVIF 16.12, CGI Conformant

Video Detection and Alarm

Trigger Events: Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection: Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
Alarm input: N/A
Relay Output: N/A

Playback and Backup

Playback: 1/4/9/16
Search Mode: Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode: USB Device/Network

Storage

Internal HDD: 2 SATA Ports, up to 10TB capacity
eSATA: N/A

Auxiliary Interface

USB: 1 USB 2.0 , 1 USB 3.0
RS232: N/A
RS485: 1 Port, for PTZ Control

Electrical

Power Supply: DC12V/5A
Power Consumption (Without HDD): <25W Construction Device Dimensions: 1U, 375mm×287mm×53mm (14.8" x 11.3" x 2.1") Device with PFH101: Rack Mount Tray: 483mmx281mmx56mm(19.0"x11.1"x2.2") Net Weight (without HDD): 2.0kg (4.4 lb) Gross Weight: 3.3kg (7.3 lb) Installation: Desktop installation Environmental Operating Conditions: -10°C ~ +55°C (+14°F ~ +131°F), 10%~ 90% RH Storage Conditions: -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH Third-party Support Third-party Support: Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more Certifications Certifications: FCC: Part 15 Subpart B ; CE: CE-LVD: EN 60950-1/IEC 60950-1; CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024; UL: UL 60950-1
